Nema 8 Actutaors 2KG Stroke 31.8mm Lead 4
Nema 8 Actutaors 2KG Stroke 31.8mm Lead 4
Price :
$136.75
- Information related to taxation
- Some question to contact us
- Shipping Information
Linear Hybird Step motors
Description
Nema 8 Actutaors 2KG Stroke 31.8mm Lead 4
Type:S20P1S31
SKU:S20P1S31
Maximum Thrust Force: 60 N (i.e., 6 kgf)
Step Angle: 1.8°
Rated Current: 0.5 A
Lead: 1.0 mm
Step Size: 0.005 mm
Lead Screw Diameter: 3.5 mm
Effective Stroke: 31.8 mm
Maximum Speed: 600 rpm (revolutions per minute)
Type:S20P1S31
SKU:S20P1S31
Maximum Thrust Force: 60 N (i.e., 6 kgf)
Step Angle: 1.8°
Rated Current: 0.5 A
Lead: 1.0 mm
Step Size: 0.005 mm
Lead Screw Diameter: 3.5 mm
Effective Stroke: 31.8 mm
Maximum Speed: 600 rpm (revolutions per minute)
Downloads
