Blue Violet Light Laser Pointer Module 5MW
Blue Violet Light Laser Pointer Module 5MW
Price :
$7.67
- Information related to taxation
- Some question to contact us
- Shipping Information
laser pointer module
Description
Blue Violet Light Laser Pointer 1MW, the diameter of the light spot is ≤ 5mm at any position within 1.5 *1.5 meter area.
Type: LP-BLV5MW
SKU: LLP-BLV5MW
Specification
Output Wavelength: 405nm br /> Laser Power: ≤5 mW br /> Operating Voltage: DC2.3V-5V br /> Spot Size: OD Operating Temperature: -10℃~+40℃ br /> Continuous Service Life: >6000 hour br /> Operating Current: 35mA-50mA br /> Irradiation Distance: >10 meter br /> Laser Operating Mode: Dot spot,continuous wave br /> Weight: 3g br /> Dimensions: frame size 7mm*21.5(23.5)mm br /> Bronze pillar: OD6mm*10.5mm br /> PCBA: 7mm*11(13)mm
Packing lsit
1x 1ed Light Laser Pointer 5MW
2x bracket and screws
Type: LP-BLV5MW
SKU: LLP-BLV5MW
Specification
Output Wavelength: 405nm br /> Laser Power: ≤5 mW br /> Operating Voltage: DC2.3V-5V br /> Spot Size: OD Operating Temperature: -10℃~+40℃ br /> Continuous Service Life: >6000 hour br /> Operating Current: 35mA-50mA br /> Irradiation Distance: >10 meter br /> Laser Operating Mode: Dot spot,continuous wave br /> Weight: 3g br /> Dimensions: frame size 7mm*21.5(23.5)mm br /> Bronze pillar: OD6mm*10.5mm br /> PCBA: 7mm*11(13)mm
Packing lsit
1x 1ed Light Laser Pointer 5MW
2x bracket and screws
