Stepper motor
Description
Stepper motor 2 phase 200 steps/Rev 2V 2.8A 57×41
Type: ST57BYG41-2804
SKU: ST57BYG41-2804
Specification
Steps per revolution: 200
Rated current : 2.8 A /phase
Rated voltage: 2V
Resistance: 0.7Ω /phase
Holding torque: 5.4Kg.cm
Inductance: 1.4mH /phase
Size: 56.4 x 56.4 x 41(L) mm
Weight: 0.45Kg
Shaft diameter: 6.35 mm
Extending Shaft length: 20.6 mm
Lead wire length: 30 cm
Including: 1x step motor
Type: ST57BYG41-2804
SKU: ST57BYG41-2804
Specification
Steps per revolution: 200
Rated current : 2.8 A /phase
Rated voltage: 2V
Resistance: 0.7Ω /phase
Holding torque: 5.4Kg.cm
Inductance: 1.4mH /phase
Size: 56.4 x 56.4 x 41(L) mm
Weight: 0.45Kg
Shaft diameter: 6.35 mm
Extending Shaft length: 20.6 mm
Lead wire length: 30 cm
Including: 1x step motor
Downloads
